QIANRENON Dual USB 3.0 Panel Mount Connector, USB 3.0 Female to Female Coupler Socket Panel Mount Pass Through Adapter，Fixed Panel Front and Rear Straight USB Extender

• 【USB3.0 dual-port connector】independent channel, independent work, no mutual influence.
• 【High transmission speed】Independent dual channel USB3.0 socket design, transmission speed is up to 5.0Gbps.
• 【Easy to Install】Integrated dual-channel USB signal connection, and save installation space, just plug the standard USB head directly for quick installation.
• 【Wide compatibility】USB 3.0 is compatible with USB3.0/2.0.
• 【Screws included】The screws that need to be installed are provided with the product,no soldering.

It is widely used in audio, video and photoelectric networks. Its base design is based on industrial standard panel apertures. Type: Connectors. Color: Black. Electrical parameters Contact resistance: <10MΩ Dielectric strength: DC1kV Frequency range: 1-100MHz Insulation resistance:> 0.5GΩ Rated current: 1.5A Rated voltage: 50V Mechanical parameters Insertion pressure: ≤ 10 N Withdrawal pressure: ≤ 10 N Service life:> 1000 times Base shape: D type Material Contact plating: 7µm Au over Ni plating Insulator: PBTP 15% GR Panel: Zinc diecast (ZnAl4Cu1) Package : 1 x USB 3.0 dual port dual channel connector;2 x screws.
