PTZ Speed Dome Camera Controller Joystick Keyboard 2D LCD Display For CCTV Security Systems

• The controlling keyboard can be used to control matching teminal devices such as high constant-speed dome PTZ cameras, decoders, etc.
• It can control as many as 128 speed dome cameras or other terminals within a maximum conmmunication range of 1.5km (4900ft) via twisted-pair.
• Control up to 128 units, each unit can be set 1-255 addresses
• Easy to set and run the preset positions and tour group.
• LCD display, as man-machine interface, LCD display board is more intuitionist, convenient, each to understand, plentiful information, etc

The controlling keyboard can be used to control matching teminal devices such as high constant-speed dome PTZ cameras, decoders, etc. It can control as many as 128 speed dome cameras or other terminals within a maximum conmmunication range of 1.5km (4900ft) via twisted-pair. Specifications: Photoelectric insulated RS485 controlling mode,strong anti-jamming and long-distance transmission (Max 1.5km) Control up to 128 units, each unit can be set 1-255 addresses Variable speed operation can be applied to the built-in Pan/tilt of camera Can control the lens zooming, focus and iris Easy to set and run the preset positions and tour group Easy to set the left and right limiting positions and run the scan between them. Home (default) position can be set up, activated and closed by the controller. LCD display, as man-machine interface, LCD display board is more intuitionist, convenient, each to understand, plentiful information, etc Technical Information: Communication: RS-485 Protocol: Pelco-D, Pelco-P, Pelco-D1, Pelco-P1, New Baud Rate: 1200 / 2400 / 4800 / 9600 / 19200 Communication Distance: 1500M (4900ft) twisted-pair Max controllable Cameras: 128 units Camera ID from: 1 - 255 Power Supply :Adaptor - Input: 100 - 240V AC - Output: DC 12V, 500mA Package includes: 1 x Keyboard Controller for PTZ CCTV Cameras 1 x User Manual 1 x Power Supply AC Adaptor (100V - 240V, world voltage)
