Pollmann Main terminal, 5-pole, HLAK 25-5/14 BSGS, 1 piece

• Main conductor: 1.5-25mm² solid/stranded, 2.5Nm | 1.5-16mm² fine-stranded – ferrule, 2.5Nm
• Branch conductor: 1.5-16mm² solid/stranded, 2Nm | 1.5-10mm² fine-stranded – ferrule, 2Nm
• Stripping length: 16 mm
• Socket terminal with 2 M6 screws per terminal point; screws with Pozidriv Z2 combination slot
• Rated current: Cu: 130 A; Al: 100 A (VDE 0611 / EN 60947-7)
• Insulation voltage: 1000 V AC / DC for: Overvoltage category III (Uimp = 8 kV, fixed installation) Pollution degree 2 (e.g. distribution cabinet installation)
• Mounting: on 35 mm DIN rail according to EN 50022 / EN 60715
• IP 20, finger-safe
• All materials and processes used are RoHS compliant

Connection technology for all applications! Pollmann Elektrotechnik offers suitable terminals within a crosssection area of 1 to 240 mm² for a variety of applications. Thus current ratings of up to 500 A are covered. Higher ratings can be offered for customized solutions. Tin-plated terminal blocks are increas ingly used for applications with solid aluminium conductors. The plugin technology becomes more popular for smaller crosssections
