obo-bettermann – Discharger Combined V50 3 Poles 280 V

• Net shape = TN – C net
• Number of Poles: = 3
• Blitz shock energy (10/350) = 12.5 KA
• Höchste time voltage AC = 280 V
• Rated Voltage AC: 230 V

The V50 Flash Power Estate drainer made from a low plastic is suitable for a lightning protection potential equalization in accordance with VDE ( – 305 (IEC 62305). A dynamic separating device and optical status display which characterize the modular plug-in drainer is off. Great with the Combi controller for lightning protection and potential equalization for building the flash protection class III and IV is the Blitzstromabableitvermögen is 12.5 Ka (10/350) Pro polarising and up to 50 kA (10/350 total). The Vibrationssichere Verrastung and the voltage and type code stickers provide safety and help prevent Verwechslungen from top and separating. Thanks to the tapered design of the contacts is easy to install and even easier removal of the upper parts possible. Power A/C power. Number of Poles: 3 lighting is power (10/350) is 12.5 mm Ka. High Constant Voltage AC is 280. rated voltage AC is 230 V. protection level is 1.3 kV. Protection level L N is 1.3 kV. Max. Conductor Cross Section fixed (you will only receive one/mehrdrähtig) is
