NUZAMAS 12V/24V Solar Panel Regulator Charge Controller 60A PWM LCD Display Double USB Ports

• Intelligent Control Interface LCD Display: 1. Graphic Symbols Display 2. System Voltage Identification 3. Intelligent PWM Charge Mode 4. Automatic Temperature Compensation 5. Charge-Discharge Statistics for Clear Use Condition
• Simple Operation: 1. Simple & Easy Button Operation 2. Adjustable Charge-Discharge Parameter, Timer & Brightness Control 3. Operation Mode of Load is Settable
• Intelligent Batteries Protect Extend Lifetime: Reverse-discharge Protection, Low Voltage Disconnection (LVD), Reverse Connection Protection, Load Short-circuit Protection, Temperature Sensor Equipped for Automatic Temperature Compensation
• Efficient Connection Port : Large Section of Connection Port for Easy Wiring， Significant Reductions to Energy Loss and Circuit Pressure Drop
• Efficient Connection Port : Large Section of Connection Port for Easy Wiring， Significant Reductions to Energy Loss and Circuit Pressure Drop

Intelligent Control Interface LCD Display: 1. Graphic Symbols Display 2. System Voltage Identification 3. Intelligent PWM Charge Mode 4. Automatic Temperature Compensation 5. Charge-Discharge Statistics for Clear Use Condition Simple Operation: 1. Simple & Easy Button Operation 2. Adjustable Charge-Discharge Parameter, Timer & Brightness Control 3. Operation Mode of Load is Settable Intelligent Batteries Protect Extend Lifetime: Reverse-discharge Protection, Low Voltage Disconnection (LVD), Reverse Connection Protection, Load Short-circuit Protection, Temperature Sensor Equipped for Automatic Temperature Compensation Efficient Connection Port : Large Section of Connection Port for Easy Wiring， Significant Reductions to Energy Loss and Circuit Pressure Drop New Design: Aluminum alloy base plate for maximized heat transfer & 2X 5V/1A USB Ports for your convenience Specifications: Model: 60A PWM Solar Charge Controller Rated Working Current: 60 Amps Rated Working Voltage: 12V/24V DC Auto Voltage of Solar Panel: ≤50V Float Charging Voltage (Settable) :13.8V/27.6V Low Voltage Protection (Settable) :11V/22V Low Voltage Recovery (Settable) :12.4V/24.8V Static Loss : <12mA Charging Circuit Voltage Drop : ≤0.26V Discharging Circuit Voltage Drop: ≤0.15V Installable Max. Cable: 2# AWG (33.62mm2) Working temperature: -25℃~55℃ Dimension: 220 mm×126 mm×63 mm Battery Type: Lead-acid/Gel battery Weight:900g Package: 1 X NUZAMAS 60A PWM Solar Controller
