Mitutoyo 128-101 Fixed Rod Depth Micrometer 0-25mm, Pink

• Ø = 4 mm measuring rod
• Ratchet stop provides you with constant measuring force.
• Measuring rod lock
• Carbide-tipped measuring rod model available
• Make sure to buy an original Mitutoyo product. This instrument is supplied by Mitutoyo UK. Buying from us means buying original Mitutoyo instruments directly from the JPese premium manufacturer with the outstanding quality, durability and accuracy that you legitimately expect.

This micrometer allows you to measure depth and offers you the following features:. The Mitutoyo Series 128 Vernier Depth Gauge, Micrometer Type, Metric, have a measurement range of 0 to 25mm, a resolution (or smallest graduation interval) of 0.01mm, with + or – 0.003mm of accuracy. The vernier scale provides precise measurements. These gauges include a 4mm diameter measuring rod for flexibility in measuring range. The units have a ratchet stop for uniform pressure and a measuring rod clamp for stability. They have a satin chrome finish on the thimble for readability. They are available with a base either 63.6mm or 101.6mm long. Depth gauges are typically used in manufacturing, machining, and mechanical engineering. Depth gauges are precision measuring instruments used to determine the depth of any shape that has a step, groove, or slot. These gauges often take the form of sliders that travel on a measuring beam or rods, are moved to position by hand, and then adjusted with a calibrated screw. The base of the gauge rests at the top of the shape whose recession is to be measured, while the beam or rods extend to the bottom of the recession to determine the measurement. Gauge position is read from a graduated scale, dial, counters, or an electronic display.Mitutoyo manufactures precision measuring tools, metrology equipment, and related systems. The company, founded in Tokyo in 1934, formed Mitutoyo America Corporation in 1963 with headquarters in Aurora, IL.
