Miniature Circuit Breaker, 1pc 250V DC 2P Low-voltage Miniature Air Circuit Breaker Solar Energy Switch 16A/32A/63A for solar panels grid system(63A)

• NECESSARY PARAMETERS: Model: C65H-DC 2P,, rated current: 16A/32A/63A (optional), rated voltage: DC250V, ultimate breaking capacity (ICU): 10kA, stroke characteristics: B, C, rated impulse withstand voltage (Uimp): 5kV.
• FUNCTION: Circuit breakers are used to protect DC circuits from overload and short circuit damage, and can also be used for control and isolation.
• EASY INSTALLATION: Modular structure, the miniature circuit breaker can be easily installed on the DIN standard rail in the distribution box (DIN rail is not included).
• OPERATION: The miniature circuit breaker is quickly closed to ensure the operation of the load and prolong the life of the electrical circuit breaker.
• WIDELY APPLICABLE: circuit breakers are widely used in solar panel grid-connected systems, wind-solar hybrid systems and many other DC systems.

Specifications: Model: C65H-DC 2P Poles: 2P Rated Current: 16A/32A/63A(Optional) Rated Voltage: DC250V Ultimate Breaking Capacity(ICU): 10kA Trip Characteristics: B, C Rated Impulse-withstand Voltage(Uimp): 5kV Current Limiting Class: 3 Mechanical Life: 20,000 times (IEC 60947-2/GB14048.2) Electrical Life: 10,000 times (IEC 60947-2/GB14048.2) Operating Temperature: -25~+70 Storage Temperature: -40~+85 Heat & Humidity Resistance: 55, 95%RH Size: 8.2 x 3.6 x 7cm / 3.22 x 1.41 x 2.75" Package Includes: 1 x Circuit Breaker
