Micvtve Brushed Motor MY6812 12V 120W High Speed Motor with Sprocket Scooter Small Brush Motor with Belt Pulley Electric Scooter

• This product is a small brush motor, made of premium aluminum material.
• The shaft diameter: 8mm (single milling slot 1mm).
• With metal belt pulley, strong, for long time use.
• The motor length of 100mm is 68mm in diameter, the shaft length is 28mm, the shaft diameter is 8mm, the distance between the 2 fixed holes of the motor is 36mm, and the sprocket wheel is the 9 teeth sprocket wheel of the 25H model.
• Suitable for electric scooter, electric bicycle, etc.

Micvtve Condition: New Item Type: Brushed Motor Model: MY6812 Rated power: 120W (kW) Rated voltage: 12 (V) Main application: scooter, electric vehicle Rated voltage range of 3C: 36V DC Rated current: less than 8, 5A Rated speed (RPM) : 2500 +/- 5% Maximum speed (RPM) : 3500 +/- 5% No-load current: less than 0.9A Rated torque: 0.56 nm Transmission: belt pulley, metal Shaft diameter: 8mm (single milling slot 1mm) Efficiency: more than 68% Sprocket: 25H 9 teeth sprocket Colour: black Material: composite material Package Contents: 1 * Brushed Motor Only the above package content, other products are not included. Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
