MG Chemicals 8331D Silver Conductive Epoxy Adhesive, 120 gram Kit

• creates strong permanent electrical connections
• electrical resistivity: 1.8 x 10-3 ·cm, thermal conductivity: 1.5 w/(m·k).
• use as a solder replacement or for bonding heat-sensitive electronic components. cures at room temperature but heat cure is recommended to get the best possible conductivity
• excellent adhesion to many substrates such as glass, soft metals and plastics
• svhc free

Silver Conductive Epoxy Adhesive 8331D is an electrically conductive, silver-filled 2-part epoxy adhesive. It is smooth, non-sagging, thixotropic, and bonds well to a wide variety of substrates.This product allows for quick, cold-soldering repairs. It can also be used as a solder replacement for bonding heat-sensitive electronic components, or for making conductive connections where soldering is not an option,such as when bonding to glass, soft metals, or plastics.8331D has been formulated to be economical. For a higher fill that maximizes conductivity, use 8330D. For a longer working time, time, use 8331S. Application InstructionsRead the product SDS and Application Guide formore detailed instructions before using this product(downloadable from MG Chemicals).Recommended PreparationClean the substrate with Isopropyl Alcohol, MG #824,so the surface is free of oils, dust, and other residues.Can or Jar1. Stir each part individually to re-incorporatematerial that may have separated.2. Measure 1.2 part by weight of A.3. Measure 1 part by weight of B.4. Thoroughly mix parts A and B together.5. Apply adhesive to the application area.Cure InstructionsAllow to cure at room temperature for 6 hours,or cure the adhesive in an oven at one of thesetime/temperature options: 10 min @ 65 ˚C 5 min @ 80 ˚CStorage and HandlingStore between 16 and 27 ˚C in a dry area, away fromsunlight (see SDS). To maximize shelf life, recapproduct firmly when not in use.
