LIBO Full RFID Access Control System Kit Set Metal Controller Keypad 1000 Users, DC 12V Electric Electronic Magnetic Lock 180kg/350lbs NC Mode, with Door Exit Button + 10pcs RFID Cards KeyFobs

• 1. Support 1000 users. Three open door method: RFID card, password, RFID card + Password.
• 2. Full Program from the number keypad, don't need to connect to computer.
• 3.Electric Magnetic Lock:180kg/350lbs holding force, NC mode: locked when power on, Waterproof: can be used in outside.
• 4. Equipped with door exit button and 10 pieces 125KHz RFID keychains. Easy to use and install.
• 5. Suitable For: Wooden door, Framed glass door, Metal door, Fireproof door, etc.

Access Controller 1.Voltage: 12VDC, Current: <1200mA 2.User capacity: 1000 users 3.Proximity Reader Frequency: 125KHz 4.Compatible Cards: EM or EM compatible card 5.External Reader: Not support 6.Reading Distance: 3-10cm 7.Door Open Options: RFID Card Only / Password Only / RFID Card + Password. 8.Full programming from the keypad, doesn't need to connect on the computer, can works alone. 9. Dimension: 120*77*27mm, Material: metal Access Control Power Supply 1.AC input: Standard AC100V-240V 50-60HZ 36W, DC output: DC12V/ 3 A 2.Set NC / NO outputs, can control various types of electric locks. 3.Automatic protection function: It will protect automatically and no voltage output when short circuit happening in the circumferential circuit. 4.Dimension:100*65*32mm, Material: metal Electric Magnetic Lock 1. Working Voltage: DC12V, Working Current: 380-500mA 2.Holding Force: 180kg/350lbs. 3.NC Mode: Fail-safe type, unlocked when power off, locked when power on. 4. Features: unfold install, Built-in voltage spike suppressor, waterproof, without LED working indicator light. 5.Suitable For: Wooden door, Glass door, Metal door, Fireproof door, etc. 6.Dimensions: 170x23x39mm / 130x33x9.3mm Door Exit Button 1.Dimensions: 86*86*8mm 2.Material: fireproof ABS plastic 3.Power Input: DC 12V 4.Output Contact: NO / COM RFID Keyfobs 1.Frequency: 125KHz, EM ID type 2.Chip: TK4100 3.Color: blue 4. Read Only 5.Quantity: 10pcs Package Including 1 x Access Control Keypad 1 x Power Supply 1 x Electric Magnetic Lock 1 x Door Exit Button 10 x RFID Keyfobs 1 x User Manual(EN)
