Legrand 049783 REX600 PLUS 230V

• Extremely quiet surface-mounted stair light switch for in existing systems, not advisable in new systems.
• 230 V, 50/60 Hz with a N/O 250 V/50 Hz, 16 A.
• Time range can be switched from 0.5 to 10 minutes, as well as manual switch for switching from minute light to continuous light.
• Dimensions: H 112mm x W 72mm Protection rating: IP 20

Legrand 049783Staircase lighting time switch 230 Volt Rex600 AP hand control f.Dauerlicht Staircase lighting time switch 230 Volt 50/60 Hz Rex 600 Plus Number of normally open contacts 1 off early without Rated switching current 10 A Frequency of the control voltage 1 50 ... 60 Hz function electronically Maximum incandescent lamp load 800 Watts Maximum switching current (cos phi = 0.6) 8 A plaster downstream connection resettable Release delay on 0.5 ... 10 minutes Circuit type 3-wire circuit Voltage type of supply voltage AC Control voltage 1 230 ... 230 Volt Control voltage 1 AC surge function selectable no Button glow lamp current 50 mA Supply voltage range 250 ... 250 Volt Specifications
