KALEA-INFORMATIQUE PCIe x4 type PCIe 3.0 controller card for SSD M.2 type PCIe 3.0 x4 NVMe or PCIe-AHCI M2

• PCIe card for mounting a high-performance M.2 SSD type PCIe 3.0 x4 NVMe or PCIe-AHCI M.2
• For PCIe Gen 3.0 4x connector (4x, 8x and 16x compatible). For SSD M2 PCIe Gen 3 and Gen 2 in 110, 80, 60 or 42mm Socket M.2 type NGFF 22110-D5-M (not compatible with M2 B Key SSDs which are Sata and not PCIe)
• The SSD can be fixed by screw adjustable according to its PCI Express 3.0 length (PCIe 2.0 compatible but the performance will be lower because the bandwidth is reduced) Compatible with double-sided SSD (1.5 mm) Pins for activity diode of the hard disk to connect to your enclosure
• Low Profile format (supplied with two brackets, high profile mounted on the board and low profile provided in the box) POWER SUPPLY 3.3V/5A HIGH POWER COOLING RADIATOR with several mounting slots possible
• No driver required, transparent hardware adapter for Windows 10, 8.1, Server 2012 R2, Linux, Fedora, SUSE, Unbutu, Red Hat natively support PCIe-NVMe & PCIe-AHCI SSDs. For use with Windows 7 or Server 2008R2, you will need to update Windows (https://support.microsoft.com/en-us/kb/2990941) Mac Pro 2009, 2012 and 2012 only support PCIe-AHCI M.2

Features: PCIe card to mount a high-performance M.2 SSD type PCIe 3.0 x4 NVMe or PCIe-AHCI M.2 type. For PCIe Gen 3.0 4x connector (4x, 8x and 16x compatible). For M2 PCIe Gen 3 and Gen 2 SSD in 110, 80, 60 or 42mm. Socket type M.2 NGFF 22110-D5-M (not compatible with M2 B Key SSDs which are Sata and not PCIe). The SSD can be fixed by screws to adjust its length. PCI Express 3.0 (PCIe 2.0 compatible but performance will be lower because bandwidth is reduced). Compatible with both sides (1.5mm) SSDs. Pins for hard drive activity diode to connect to your case. Low Profile format (supplied with two brackets, high profile mounted on the board and low profile provided in the box). No driver required, transparent hardware adapter for the operating system. Windows 11, 10, 8.1, Server 2012 R2, Linux, Fedora, SUSE, Unbutu, Red Hat natively support PCIe-NVMe & PCIe-AHCI SSDs. For use with Windows 7 or Server 2008R2, you will need to update Windows (https://support.microsoft.com/en-us/kb/2990941). Mac Pro 2009, 2012 and 2012 only support PCIe-AHCI M.2. Operating temperature: -40°C to +80°C. 3.3 V/5 A high power supply. COOLING RADIATOR with several mounting locations possible. RoHS Components
