ITAP-FIT -IT650C000015 Brass Connector Angle Coupling for Copper Pipe Diameter 15 mm - DVGW

• ITAP-FIT brass connector for copper pipe // Design: angled coupling with pipe connection on both sides 15 mm
• Material: untreated brass with anti-inclination (DZR)
• Nominal pressure: 20 bar at 25 °C and 10 bar at 90 °C. Operating temperature: -20 °C to max. +130 °C
• Approvals: DVGW – approved for drinking water and heating systems. These connectors can be used for copper pipes (RAL, semi-hard, pulled) as drinking water pipes, in heating construction, air pressure systems and industry.
• Note: After assembly of the connectors and piping, always a pressure sample (DIN4279). In the event of failure to perform and/or loss of written evidence, no compensation will be paid by the manufacturer.

ITAP-FIT brass connector for copper pipe, design: angle coupling with both sides pipe connection, material: untreated brass with zinc protection (DZR), nominal pressure: 20 bar at 25 °C and 10 bar at 90 °C, operating temperature: -20 °C to max. +130 °C approvals: DVGW - approved for drinking water and heating systems. These connectors can be used for copper pipes (RAL, semi-hard, dragged) as drinking water pipes, in heating construction, air pressure systems and industry. Note: After fitting the connectors and pipe laying a pressure sample (DIN4279) must always be performed. In the event of non-execution and/or loss of written evidence, no damages will be taken over by the manufacturer.
