Intel RS3DC080 8 Channel RAID Storage Controller - Multi-Colour

• Interface: SATA 6Gb/s / SAS 12Gb/s low profile
• Data Transfer Rate: 12 GBps
• RAID Level: RAID 0, 1, 5, 6, 10, 50, 60
• Bus Type: PCIe 3.0 x8
• 8 Channel

Product Description The Intel RAID Controllers RS3DC080 doubles the available bandwidth of current 6 GB/s SAS solutions and offers a higher level of RAID performance and security compared to entry-level products. They feature eight and four internal ports respectively, deliver two 12 GHz processor cores and 72-bit DDRIII interface that drives 1 GB cache memory at 1866 MHz They support 8 PCI Express lanes that comply with the latest PCI Express 3.0 specification with 8 gig transfers per second (GT/s) per lane. Plus, each adapter supports 8 individual SAS ports operating at 12 GB/s. The Intel RAID Web Console 2 included in these adapters enhances RAID volume creation by empowering administrators to further optimize their storage for application performance and data protection. With an intuitive graphical user interface, this Intel RAID Web Console 2 deploys all the critical system storage functions and helps eliminate complexity and learning curves. Plus, since all Intel RAID solutions are validated across multiple platforms with Intel boards, chassis, and systems, when used together they deliver the best combination of performance, built-in. Box Contains Raid Controller, Quick Start User Guide, 1 standard & 1 Low Profile bracket
