Inductive Proximity Sensor, 10mm Distance 3-Wires PNP Normally Open Inductive Proximity Approach Sensor Switch Detector LJC18A3-B-Z/BY Nickel Plated Brass Magnetic Proximity Sensor DC12-24V

• 【 Strong Anti-Interference 】This LJC18A3-B-Z/BY PNP 10mm proximity sensor switch has great sensing performance, action and fast frequency response. No mechanical wear and fatigue damage, strong anti-interference capability
• 【 Non-Contact Detection 】 PNP Normally Open Proximity Approach Sensor non-contact detection avoids the sensor and the target object from damages. The switch stays open, and closes when it detects object in detection distance
• 【 Wide Application 】Inductive Proximity switch, also known as contactless proximity switch, a position sensor with switch output that can be connected with microcomputer. Widely used in automatic control industry for positioning control, counting, automatic and more
• 【 Automatic Control 】The DC Type 3-Wires Proximity switch also can drive directly from, electromagnetic relays, counters and contactor to achieve automatic control purposes. Widely used in automatic control industry for detecting, controlling, and non-contact switching
• 【 Warranty 】 We are here with a product promise to give you the best in customer care! Please feel to contact us if you are not satisfied with it for any reason. We promise all the issue will be solved within 24 hours

Description Specification: Condition: 100% brand new Material: brass plated nickel shell, ABS detection surface Weight: 111g/3.9oz Detection distance: 10mm ±10% Set distance: 0-8mm Lag distance: less than 10% of the detection distance Detection object: any dielectric substance Standard test object: iron SPCC 50*50*1mm Response frequency: DC:0.5kHz AC:25Hz Power supply voltage: DC 12-24V (6-36V) ripple (p-p) less than 10% (DC type) Withstand voltage: AC1000V 50/60Hz 1min between the charging part and the shell Voltage influence: within the rated power supply voltage range of ±15%, within the detection range of ±10% when it is the rated power supply voltage value Current consumption: N.P type: below 13mA D type: below 0.8mA A type: below 1.7mA Control output: N.P type: below 300mA D type: below 200mA A type: below 400mA Circuit protection: N.P.D type: reverse connection protection, surge absorption, load short circuit protection A Type: surge absorption Ambient temperature: each - 30 to + 65 ℃ action and save Ambient humidity: 35-95% RH each (no ice, no frost) action and save Temperature influence: Temperature range -30 to + 65 ℃ , +23 ℃, ± 15% detection distance; Temperature range -25 to + 60 ℃, +23 ℃, ± 10% detection distance. Insulation resistance: more than 50mΩ (DC500 megger) charge between parts and the shell Package List: 1 x Proximity Sensor Switch
