RIVERWELD Hi Lo Welding Gauge Gage Test Ulnar Welder Inspection Gauge Both Inch and Metric Checks Internal Misalignment Pipe Wall Thickness Leg Length for a Fillet Weld Crown Height

• Both Inch and Metric
• Measure fit- up gap Measure bevel on end preparation; Measure the crown height of welds; Measure fillet weld size; Measure scribed line, socket welds; Can be calibrated to NBS standard.
• Changes from standard to metric simply remove gauge body, turn scales over and replace body; Measure internal misalignment
• HI-LO WELDING GAGE MEASURES INTERNAL ALIGNMENT Of pipe after fit-up alignment, cuts radiographic rejects. Measures internal misalignment of pipe before and after tacking. Measurements read in standard one side, and metric on the opposite side.
• Stainless Steel

HI-LO WELDING GAGE MEASURES INTERNAL ALIGNMENT Of pipe after fit-up/ alignment, cuts radiographic rejects. Measures internal misalignment of pipe before and after tacking. Measurements read in standard one side, and metric on the opposite side. Changes from standard to metric simply remove gauge body, turn scales over and replace body; Measure internal misalignment; Measure fit- up gap Measure bevel on end preparation; Measure the crown height of welds; Measure fillet weld size; Measure scribed line, socket welds; Can be calibrated to NBS standard.
