HELLA 8KV 713 222-812 Cable Connector - from: 1.0mm² - to: 1.5mm² - Blade Terminal/Round Connector Sleeve - Kit

• Line connection and insulation in one integrated product
• Wide range with all common contacting variants
• Quick and easy connection of cables
• Different identification colours for different cable cross-sections
• Quantity Unit: Set
• Cross Section [mm²] from: 1,0
• Cross Section [mm²] to: 1,5
• Plug Type: Round Connector Sleeve, Blade Terminal

Insulated crimp connectors are crimped at the coloured end with an appropriate tool to make a secure, firm contact with the cable. The insulation material is either PVC (max. temperature rating of 80°C) or nylon (max. 105°C). The insulating sleeve has a special "easy-entry" funnel shape to ensure better insertion of the cable. Identification colour red: Crimp connector for cable cross-section 0.5 - 1.0 mm². Identification colour blue: Crimp connector for cable cross-section 1.5 - 2.5 mm². Identification colour yellow: Crimp connector for cable cross-section 4.0 - 6.0 mm².
