Hantek PP-150 Oscilloscope Probe 1x 10x 100MHz Oscilloscope Clip Passive BNC Scope Clip Probe

• Safety standards: it has passed the CE Attestation of European Community
• Attenuation ratio: 1× and 10× optional
• Portable design according with ergonomics
• Integral injection molding makes the usage more flexible and the oscilloscope able to adapt more testing situations

Integral injection molding makes the usage more flexible and the oscilloscope able to adapt more testing situations. Attenuation ratio: 1x and 10x optional. Compatible with domestic and international digital and analog oscilloscopes in relevant frequency. Features: Performance & Characteristics Attenuation ratio: 1× and 10× optional. Portable design according with ergonomics. Integral injection molding makes the usage more flexible and the oscilloscope able to adapt more testing situations. Safety standards: it has passed the CE Attestation of European Community. Specifications: Attenuation:x1 x10 Input resistance:1MΩ: 10MΩ Input capacitance: x1: 85pF-115pF x10: 18.5pF-22.5pF Compensation scope: 15pF-35pF System bandwidth: x1: DC-6MHz x10: DC-100MHz Input voltage: x1:<200V DC +Peak AC x10: <600V DC +Peak AC Weight:55g Cable length:120cm Temperature scope:Operation: -10℃--+50℃ Not Operation: -20℃--+75℃ Humidity: ≤85% (Relative humidity) Application Fields: Compatible with domestic and international digital and analog oscilloscopes in relevant frequency. Measurement in intermediate and low frequency signals. Package Including: Accessories included by PP series passive voltage rapier ● Operation manual ● Adjusting tool: adjusts compensation capacitance to assure the rapier match with oscillograph. ● Contractive-type acuminate hook ● 12cm earth wire with alligator clip ● 3 pairs of colorized cable markers ● Locating sleeve adapts to IC testing.
