HangTon TY28 4 Pin 45Amp Solder-free Aviation Waterproof Quick-Disconnect Connector Male Female Cable Plug Socket Screw-Crimp for Power Device

• TY28 4-pin waterproof free-solder screw crimp connector, easy for assembly cable
• Features Waterproof IP68, threaded coupling, quick disconnect. The contact pins of the connector are pure copper gold-plated, which has strong conductivity, corrosion resistance and oxidation resistance
• Rear panel mount female socket and cable plug with watertight cap
• Rated Voltage/Current AC 380V/45A, Contact resistance 0.5mΩ, Insulation resistance 2000mΩ. Suitable wire outer diameter range 10-15mm, Wire gauge 6mm² or 10AWG, Contact Diameter Φ3.6mm
• Protected against solids and liquids, provide a secure and reliable power connection in the harsh environment

Features: The connector can provide a safe and reliable connection in the harsh environment . TY28 series connector is ideal for watertight power equipment applications, outdoor electric tools or appliances, camper van truck power, communications, marine equipment, under water equipment, outdoor led lighting, outdoor LED panels, solar energy system, outdoor security cameras, transformer, control box. Specifications: TY28: Model: 2 3 4 5 6 7 9 Pin IP Rating: IP68 Panel Cutout Diameter: 28.5mm Cable Outer Diameter Range:10-15mm Coupling Type: Threaded Coupling Shell material: Thermoplastic Nylon66, Fire Resistance: V-0 Insert Material: Thermoplastic PA66, max temperature 200℃ Contact Material: Pure copper plated gold Wiring way: Free-Solder / Screw Crimp Mating Cycle: >500 times Temperature Range: -25~+85℃ Package Includes: 1 x Plug with male contact 1 x Socket with female contact 1 x Waterproof / Dustproof Cap
