Garosa H7EC-N without Input Voltage LED Digital Counter Meter Digital Electrical Counter 8 Digit LCD Display 0-99999999 Counting Range Digital Totalizer with Holder

• EASY TO INSTALL: The digital electronic counter is a standard panel mount model that is easy to install.
• ACCURATE AND RELIABLE: The digital electronic counter is designed with 8 digits for accurate and counting.
• DIGITAL COUNTER: This is a digital counter with no mechanical wear and long service life, instead of an electromagnetic counter.
• LCD DISPLAY: The digital electronic counter is equipped with a liquid crystal display for clearer readings.
• BUILT-IN BATTERY: The lithium battery of this digital electronic counter is built-in. The theoretical life of the battery can be as long as three years and the memory time is long.

Specification: Model: H7EC-N Counting format: 0-99999999 LCD display number: 8 digits Display type: LCD - black character Input type: no voltage External power supply: Do not (built-in 3V 800mA lithium-ion battery) Input: count input / reset input Reset: external reset / manual reset (minimum reset signal time 20ms) Working temperature: -10 - +55°C (no ice or condensation) Storage temperature: -25 - +65°C (no ice, condensation) Working humidity: 25~85% Panel opening size: 44.5MM*22.5MM Installation type: panel mounting Terminal Type: Screw Terminal Intrusion protection: IP66 - dustproof, water resistant Protection: IEC standard IP66, US NEMA standard type 4 (indoor) (but only panel surface) Anti-noise: Square noise generated by the noise simulator (pulse width 100ns, 1μs rises 1ns) Antistatic force: ±8kV (misoperation) Vibration durability: 10 ~ 55Hz, single amplitude 0.375mm, 3 directions, each 2h Malfunction: 10 ~ 55Hz, single amplitude 0.15mm, 3 directions, each 10min Impact durability: 300m/s2, 6 directions, 3 times each Package list: 1 * Counter Note: The actual product color may deviate from the photo due to light. There may be a slight deviation in the measurement of product.
