Flush / Shoot Bolt Suitable For Aluminium Doors flushbolt concealed door

• Smooth lever action flush bolts
• Mounted in the leading edge or inside face of the passive leaf of a pair of doors
• All fixings included for easy assembly
• Strong zinc plated hardened steel bolt with anti-rattle sleeve
• Conforms to EN 1154

These FB-6200, FB-6300 and FB-6400 series finger-operated flush bolts work to secure the passive leaf on double aluminium door assemblies. They are rebated into the leading edge or inside face of the door and operated by a lever which sits flush when the bolt is engaged and the door is closed. To ensure ease of operation, FB series flush bolts have a deep finger recess and large lever. A standard installation requires two flush bolts morticed into the top and bottom of the door. For maximum security the flush bolt has a hardened steel bolt, zinc plated with an anti-rattle sleeve. Key features: Smooth lever action flush bolts Mounted in the leading edge or inside face of the passive leaf of a pair of doors Radiused faced or flat faced available Lengths 305mm Silver satin chrome finish Strong zinc plated hardened steel bolt with anti-rattle sleeve 18mm bolt stroke Fully threaded 7mm zinc plated steel rod can be cut to size for non-standard door installations A centre punch helps locate the centre of the keep All holes are pre-drilled and countersunk for M fixings All fixings included for easy assembly Guarantees & accreditations: Conforms to EN 1154
