Finder Mini Relays 40 Series, 5 mm, 1 Switch, 16 A, 12 vdc

• Standard power relay for sockets and PCB.
• Has large energy reserves.
• Includes switching control currents.
• With protective and on-board diagnostic functions.

RELAY, 16 A, for base lamp or scale Platt enmontage. Contact Material: AgCdO, contact pin data raster 5.0 mm, spool: 12 V DC, 0.65 W, 220 OHM, temperature range: -40 to + 85 °C,. Dielectric Strength Between Coil and Contacts (1.2/50 µs) 6 KV, air and kriech reach 8 mm Implementation of the electric connection is other forms. Removable, with clamps is No. tax base concussive actuator US in case of DC voltage is 12.. 12 V. Voltage DC, polarity is ungepolt. schaltve rhalten of Dell unit is monostabil. Number of Contacts as bottle opener 0. Number of Contacts is as no 0. Number of Contacts is as changes is 1 with zwangsgeführten contacts is no. The nature of the changing kontaktes is easy contact. Complete with attachment device is no. International Protection (IP) is IP20. Width 12.4 mm, Height 25 mm Depth is 29 mm Limited current is 16 5 mm grid finder slot/printrel.12VDC 1 W16 A raster 5 mm 40.61.9.012.00008012823244259
