EsportsMJJ 39Mm Hollow Shaft Hybrid Stepper Motor 4 Phase 5 Wire Square 1.8 Degrees Stepper Motor

• Length:39mm
• Height:22mm
• Output shaft:8 mm(middle of the through-hole diameter of 6.15mm)
• Output shaft length:13mm
• Step Angle:1.8 Degree

Description: 39MM Hollow Shaft Hybrid Stepper Motor 4 Phase 5 Wire Square 1.8 Degrees Stepper Motor Specifications: Length:39mm Height:22mm Output shaft:8 mm(middle of the through-hole diameter of 6.15mm) Output shaft length:13mm Step Angle:1.8 Degree Resistance:Intermediate tap:54 ohms Both Ends: 108 ohms Lead:5 Cable length:140mm 12V Short circuit current:Intermediate Tap:0.2 A, Both Ends: 0.1A Rated Voltage:DC 12V Rated Current:0.05A Rated Power:5W Weight:60G Note: Motor is a two-phase six-wire stepper motor, but inside the wiring put two phases middle of tap connected to a second terminal, so from the outside look, it is a four-phase five-wire stepper motor. Package included: 1x Hollow shaft Hybrid Stepper Motor
