Eltako Bus Switch Actuator FSR14 4x RS485

• Switching devices, power supplies and electronic electricity meters
• For building installations and control technology
• Package dimensions (L x W x H): 12.0 x 2.5 x 8.0 cm
• Country of origin: Germany

Surge switch relay with 4 channels, 1 contactor 4A/250V AC, incandescent bulbs 1000W, potentially separated from the supply voltage, with DX technology. Bi-directional Standby loss only 0.1 watts. Modular device for mounting on support rail DIN-EN 60715 TH35. 1 division unit = 18 mm wide, 58 mm deep. Connect to Eltako RS485 Bus Cross wiring bus and power supply with bridge. With the patented Eltako Duplex technology, the normally potential-free contacts can still switch in zero passage when switching 230 V AC voltage 50 Hz and thus drastically reduce wear. Simply connect the N conductor to the terminal (N) and L to K(L). This results in an additional stand-by loss of only 0.1 watts. If all 4 relays of the FSR14-4x are switched on, 0.7 watts are required. In the event of the supply voltage failure, it will be switched off. The channels can be independently learned as an ES and/or ER channel. Scene control: with one of the four control signals of a button learned as a scene button with double rocker, multiple channels of one or more FSR14-4x can be switched on or off at a scene. Central commands on the PC are sent with the building radio visualization and control software GFVS. Learn one or more FSR14-4x on the PC. With the rotary switches, the buttons are learned and if necessary, the 4 channels are tested. For normal operation, the middle and lower rotary switch are then set to AUTO The upper rotary switch may be For all channels, the EW time (0-120 seconds) for relay or the RV time (0-120 minutes) for impulse switch. If radio motion brightness sensors FBH are learned, the upper rotary switch is separated for each channel, the switching threshold is determined, depending on the brightness (in addition to movement), the lighting switches on or off (from approx. 30 lux in position 0 to approx. 300lux in position 90).
