DSLRKIT Gigabit 24V PoE Injector Adapter UAP AC LR LITE POE-24 12W-G 24W-G 7W-G

• Passive PoE devices that support MikroTik PoE with an input voltage of DC 8-30V or 18-30V

This is a special POE adapter with 24V DC out, it can not Compatible with 802.3af(48v), please confirm your device is using DC 24v before you puchase this adapter. If you can not figure out the voltage of your device, we suggest you to buy 48v POE adapter which can follow 802.3af agreement. This injector can power 24V PoE compatible devices without extra adapters. Just plug the network cable(not included) into your network switch and the "LAN" port, then plug the network cable to your device into the "PoE" port with your existing network cable. This Adapter support 10/100/1000Mbps gigabit ethernet connection, RJ45 PoE port using 4,5,7,8 pin as power transfer, Please do not connect any nonePoE device that does not support the "PoE" port, this will damage your device. Specification: CAT5 Ethernet Pin Usage: Data: 1,2,3,4,5,6,7,8 Power: +(4,5),-(7,8) LED: Power Voltage Input: AC 100-240 V 50/60Hz Voltage Output: DC24V 1A Netork Type: 10/100/1000 Ethernet Dimension : 84 x 47 x 56mm Weight -- 106g Compatible 24V Ubiquiti PoE: UBNT AP/UAP UAP-LR UAP-AC-LR UAP-AC-LITE NanoStation M2 / NSM2 NanoStation M3 / NSM3 NanoStation M365 / NSM365 NanoStation M5 / NSM5 NanoStation Loco M2 NanoStation Loco M5 NanoStation Loco M9 Ubiquiti Rocket M5,M2,M9,M900 Ubiquiti Rocket M3/M365 Ubiquiti Rocket M2 Ubiquiti Rocket M9/M900 NanoBridge NBM9, NB-2G18, NBM3, NBM365 PowerBeam M5 PBE-M5-300-ISO airGrid M AG-HP-2G16, AG-HP-2G20, AG-HP-5G23, AG-HP-5G27 LiteBeam M LBE-M5-23, LBE-5AC-23, LBE-5AC-16-120 NanoBeam M NBE-M2-13, NBE-M5-16, NBE-M5-19 PowerBeam PBE-M5-300, PBE-M2-400 airMAX YAGI Antenna AMY-9M16 LiteBeam LBE-M5-23 Item Included: Gigabit 24V 1A PoE Injector Power Over Ethernet Adapter x1
