DSD TECH HM-11 Bluetooth 4.0 BLE Module with 6 PIN Board Compatible with iOS Devices for Arduino

• Core module is Original HM-11 module, DSD TECH brand and we accept without any excuse.
• The same AT Command with HM-10. Main Chip is CC2541F256, Compatible with iOS 7 or later and Android 4.3 or later
• DSD TECH 6 PIN base Board, leads to VCC, GND, TX, RX,STATE,EN. You can be very convenient to connect to your arduino project or other DIY project
• Working voltage 3.6 V to 6V,Default baud rate is 9600.
• DSD TECH back this HM-11 Bluetooth 4.0 module with ONE YearIf you meet any question, please contact us, we will fix your issue within 24 hours

This is a Bluetooth 4.0 LE module that can support iOS device(iphone and ipad) But does not support the version is lower than the android 4.3 phone(it don't support classic bluetooth 2.0 spp features) Operating voltage: 3.6V to 6V The AT commands of the HM-11 module are fully compatible with the AT commands of the HM-10 module. Bluetooth master and slave module Through the AT command, you can set this bluetooth module to the master mode can also be set to slave mode, even in iBeacon way work .it also Supports Apple Notification Center Service (ANCS) How to Enable Apple Notification Center Service (ANCS) ANCS function 1.1 Please read apple notification ducument first 1.2 Send AT+TYPE3 command change to AUTH and BOND mode. 1.3 Send AT+ANCS1 command to open ANCS. 1.4 Send AT+PASS[para1] command to set passcode. Default passcode is "000000" 1.5 Send AT+RESET to restart module. Now you can use LightBlue to scan and made a connect with module. iOS will ask you input passcode. please input your passcode value. If all is okay, you should receive AT+ANCS[para1] command from module UART. About HM-11 Module Core module is the original HM-11 module, not fake. DSD TECH brand guarantees and we accept refund without any excuse. WARRANTY We back this item with ONE YEAR WARRANTY. If you meet any question, please contact us, we will fix your issue within 24 hours.
