DollaTek AC Voltage and Current Meter Dual Digital Display 40~400V/100A High-precision Digital Meter Voltmeter Ammeter

• New appearance industrial design.
• Integrated built-in transformer design.
• The voltage terminal is recessed to prevent electric shock.
• Current non-contact measurement, safe and non-heating.
• The backlight can be turned on or off by short pressing the button.

Adjustment: The product is 100% calibrated before leaving the factory, and the user can also manually adjust the error by himself. The method is as follows: Step 1: Long press the button (about 3 seconds) until the digital digit on the screen flashes, then release the button; Step 2: Digital flashing means entering the error adjustment state, the digits flashing cyclically, followed by: high voltage>Voltage middle position>voltage low position>voltage decimal point>current high position>current middle position>current low position>current decimal point. Flashing represents the current adjustable digit. Short press the button to adjust the value (digit 0-9 cycle, decimal point shift); Step 3: After the adjustment is completed, press and hold the button (about 3 seconds), the screen displays PASS and returns to the normal display interface, indicating that the adjustment is successful. Feature: Voltage measurement range: 40-400V Measurement accuracy: ±1% Display format: <100V Display mode: 80.0V. ≥100V Display mode: 220V. Current measurement range: 0-100A Starting current: 0.02A Measurement accuracy: ±1% Display format: <10A (display method: 1.00A), <100A (display method: 10.0A), ≥100A (display method: 100A) Package includes: 1 x Digital Meter Voltmeter Ammeter
