Distribution Block for AL/Cu 10x2,5 35 mm2 Grey/Blue/Yellow/Green Insulation 1000 V AC/DC Clamp OTL 35 – 5X MAA5 035 A10 4399
★★★★★
$86.99
Quantity
1
Worldwide shipping
Fast tracked delivery
30-day returns
Hassle-free returns
Secure checkout
Safe & protected
Great service
Thousands of happy customers
About this item
- Application: This distribution block is suitable for connecting aluminium and copper conductors; number of poles: 5; design: 10 x Al/Cu 2.5 - 35 mm²; input/output: 5/5; cross section: 2.5 to 35 mm²
- Rated voltage: 1000V AC/DC; rated current: 5x Al - 120 A, 5x Cu - 135 A; torque screws: 3 Nm (2.5 - 16 mm2), 6 Nm (25 -35 mm²)
- Mounting type: DIN rail or mounting plate, Allen key size 4; material: body - polyamide 66, conductive parts - aluminium tin-plated, screw - aluminium tin-plated
- Colour: grey/blue/yellow-green; weight: 100 g; protection class: IP20; operating temperature: from -25°C to +80°C; burning behaviour: UL 94 V-0
- Type: OTL 35-5x. Halogen-free. Standard references/approval: EN 61238-1, EN 60947-7-1, EN 60998-2-1, CE
Product description
* Application: This distribution block is suitable for connecting aluminium and copper conductors; number of poles: 5; design: 10 x Al/Cu 2.5 - 35 mm²; input/output: 5/5; cross section: 2.5 to 35 mm2 * rated voltage: 1000V AC/DC; rated current: 5x Al - 120 A, 5x CC. u - 135 A; torque screws: 3 Nm (2.5 - 16 mm²), 6 Nm (25 – 35 mm²) * Mounting type: DIN rail or mounting plate, Allen key size 4; material: body - polyamide 66, conductive parts - aluminium tin-plated, screw - aluminium tin-plated. Colour: grey-blue-yellow-green; weight: 100 g; protection class: IP20. ; operating temperature : from -25°C to +80°C; Burning behaviour: UL 94 V-0 * Type: OTL 35-5x. Halogen-free. Standard references/approval: EN 61238-1, EN 60947-7-1, EN 60998-2-1, CE
