DIGITEN DC12V 4 Digital Green LED Counter Meter Plus Minus+Proximity Switch Sensor NPN

• Power requirement:12VDC.
• Counting:Plus or minus.
• Counting value be retained when power failure.
• Widely use in Automatic Burden System,Winding Machine,packaging machinery,textile machinery,etc.

Features High-speed IC,bright red LED,easy to install. Good stability, strong Anti-interference. Counting value be retained when power failure. Widely use in Automatic Burden System,Winding Machine,packaging machinery,textile machinery,ect. The meter retain the number automatically when power cut off. Specifications: Counter working voltage:DC12V/24V,sensor working voltage:12V. DC Current: 30mA Sign:Pusle signal,NPN 3 wires normally open trigger mode: rising edge Display dimension: 0.56" Green LED Reset signal:Pulse or switch Counting:Plus or minus Response frequency: 100HZ Display range:0-9999 Panel cutout dimension:76.5mm*39.2mm Overall dimension: 79mm*43mm*30.5mm Sensor dimention: M12x10x55mm. Detection distance: 4mm Sensor wiring:brown-Power+;blue-Power-;black-signal. Operating temperature: 0 to 50℃. Packaging include 4 Digit green counter x 1 NPN proximity sensor x 1 4 wires cable x 1 2 wires cable x 1 Instruction x 1
