DEWIN Time Relay,Time Delay Relay, DIN Rail Type AC/DC24V-240V(GRT6-B1)

• 1. Main purpose: time relay, ultra-large delay range: 0.1s-10 days, the delay can be set via the button on the control panel.
• 2. Technical parameters: voltage range: AC/DC24V-240V (50/60Hz), load: AC 0.09-3VA/DC 0.05-1.7W, output contact: 1SPDT (1NO1NC), contact capacity: 10A/AC1, setting mode: rotary knob.
• 3. Flame retardant material: the time relay is made of flame retardant PC material and high-quality electronic components, with fast response speed, stable performance and long service life.
• 4. DIN rail mounting: the working status of the time relay is clearly visible via the LED indicator. Compact size, easy to install and remove, can be mounted on 35mm DIN rail.
• 5. Wide range of applications: the time relay can be used in industrial equipment, lighting control, control of heating elements, motors, electric motors, fan controls and so on.

Specifications: Material: PC Power Connection: A1-A2 Voltage Range: AC/DC 24V-240V (50/60Hz) Load: AC 0.09-3VA/DC 0.05-1.7W Supply voltage tolerance: -15%, ±10% Power indication: Green LED Timeframe: 0.1s-10 days Time setting: Potentiometer Time deviation: 10% - mechanical setting Repeat accuracy: 0.2% setting value stability Output Contact: 1SPDT (1NO1NC) Contact capacity: 10A/AC1 Output indication: Red LED Mechanical life: 1x10(7) Electrical Life: 1x10(5) Reset time: Up to 200ms Protection level: Front panel: IP40, connection: IP20 Maximum cable size: Maximum solid wire: 1x2.5 or 2x1.5/with sleeve maximum: 1x2.5 (AWG 12) Product Dimensions: 90*18*64mm Notes: Due to different monitors and lighting effects, the actual colour of the item may be slightly different from the colour shown in the pictures. Please allow 1-3 cm measurement error due to manual measurement. Thank you for your understanding! Packing List: 1*Time Relay 1*User Manual (English)
