CUEI 12V Anti Fog Waterproof Depth Sounder, 2.0 inches LCD, Up to 100m, With Transducer & 10m Cable, White Backlight, For Yachts, Fishing Boats, Pontoon Boat

• 【HIGH PRECISION】Press keypad Mode to switch SH, DP, KL, UN function. Used to turn on or off the monitor. Short press to set the value required, and keep the digital increasing or decreasing fluently. Depth sounder transducer, depth sensor, depthtrax. Algorithmic programming significantly reduces false readings and produces unmatched precision.
• 【FAST RESPONSE】The working voltage is 9‑32V, up to 36V, low power consumption, long life, high accuracy, short start up time, the highest depth indication of 100m, you can instantly know the depth of the water. The sonar technology allows for depth readings through solid fiberglass hulls and up to 1/8-inch aluminum hulls.
• 【INTELLIGENT ALARM SYSTEM】This in dash digital depth sounder is work with 12V system only, to indicate the depth appointed. Normally, the buzzer beeps once when it was connected correctly then turn on the power. 3 stage Advanced Warning System clearly signals an alarm condition with an audible alarm, an ultra bright red LED warning light and LCD alarm indicators.
• 【DURABLE WATERPROOF MATERIAL】Made of stainless steel 316L bezel and anti fog glass, it has excellent anti fog and waterproof properties, and can be used for a long time even in cold sea environments. If you have any questions about fishing boat water depth gauge with alarm function, please do not hesitate to contact us by email and we will try our best to solve your problems.
• 【WIDE APPLICATION】Delivers uninterrupted depth readings from 0-100m/0-328 feet on the largest display available on an In-Dash Depth Sounder. Easy to install, good durability, impact resistant, flexible and easy operation, suitable for yachts, small and medium sized boats, fishing boats and other types of marine transportation.

Specification: Item Type: Depth Sounder Material: Stainless steel 316L, anti fog glass, ABS Mounting Hole Diameter: Approx. Φ52mm/2in Depth Indication Range: 0-100m/0-328FT Backlight Color: White Operating Voltage: DC 12V Instantaneous Voltage: DC 9-32V, up to 36v Operating Current: 60mA Operating Temperature: -30 °C- + 75 °C Storage Temperature: -40 °C - + 85 °C Dial Waterproof Rating: IP67 Back Cover Waterproof Rating: IP5 Operation: A. This device is work with 12V system only, to indicate the depth appointed. Normally, the buzzer beeps once when it was connected correctly then turn on the power B. Keypad''Mode'': Quick press the keypad''Mode'' to switch SH/DP/KL/ UN Hold the keypad''Mode'' to turn on/off the monitor Short press the keypad''▲''''▼''to set the value required Hold the keypad''▲''''▼''to keep the digital increasing/decreasing fluently. Parameter: SH: (Low level alarm) Range: 0-0.6-19.9, when the level no more than value(SH) appointed,the symbol flickering and the buzzer beeps all the time. If SH=0 -->No alarm Alarm setting range :0.6-19.9 Range: 1). Unit''M'': 0-99 2). Unit''FT'':0-199 3). Unit''F'': 0-49 If the level exceed the a ppointed value , the buzzer will beeps twice Keel offset (KL): Range: 1). Unit''M'': 0-6.0 2). Unit''FT'':0-19.9 3). Unit''F'':0-3.3 Package List: 1 x Depth Sounder 1 x Transducer (with 10m cable) 2 x Screw 1 x Power Cord 1 x Manual
