DC Gear Motor 6V 12V N20 Gear Box Reduction Motor with Long Output Shaft M4 x 100mm(12V 600RPM)

• 【LOW SPEED AND LOW NOISE】This DC motor features large moment of force, low speed, and low noise
• 【LONG SERVING LIFE】The motor is made of metal gear, wear-resisting, avoid tooth breaking, so with long serving life
• 【USEFUL AND PRACTICAL】This electronic gear motor is good replacement for old or worn electronic deceleration motor, useful and practical
• 【SUITABLE FOR】Suitable for lifts, landing gear, mechanical arms ,electronic toys and many other devices
• 【LOW HEAT AND LOW LOSS】This motor is adopted of pure copper wire coil, with low heat and low loss

Specification: Model: GA12N20-M4100 Rated power: 2W Optional type: 6V 30RPM, 6V 60RPM, 6V 100RPM, 6V 150RPM, 6V 200RPM, 6V 300RPM, 6V 400RPM, 6V 500RPM, 12V 300RPM, 12V 400RPM, 12V 600RPM 3C rated voltage range: Tread type: M4 Output shaft length: 100mm / 3.9inch Length: Approx. 125mm / 4.9inch Weight: Approx. 19g / 0.7oz Voltage Gear Ratio No Load Load Torsion Stall Speed Current Speed Current Torsion Current Torsion 6V 1:298 30RPM ≤40mA 23RPM ≤40mA 440gf.cm ≤1.1A 3.3kgf.cm 6V 1:298 60RPM ≤40mA 50RPM ≤40mA 560gf.cm ≤1.1A 3.6kgf.cm 6V 1:100 100RPM ≤50mA 83RPM ≤45mA 320gf.cm ≤1.1A 2.25kgf.cm 6V 1:100 150RPM ≤50mA 130RPM ≤45mA 260gf.cm ≤1.1A 2.50kgf.cm 6V 1:50 200RPM ≤50mA 180RPM ≤45mA 160gf.cm ≤1.1A 1.60kgf.cm 6V 1:50 300RPM ≤50mA 240RPM ≤50mA 190gf.cm ≤1.1A 2.0kgf.cm 6V 1:50 400RPM ≤50mA 350RPM ≤70mA 210gf.cm ≤1.1A 2.2kgf.cm 6V 1:50 500RPM ≤70mA 440RPM ≤100mA 220gf.cm ≤1.1A 2.4kgf.cm 12V 1:100 300RPM ≤50mA 240RPM ≤60mA 550gf.cm ≤1.1A 3.6kgf.cm 12V 1:50 400RPM ≤50mA 310RPM ≤45mA 280gf.cm ≤1.1A 2.4kgf.cm 12V 1:50 600RPM ≤50mA 500RPM ≤50mA 310gf.cm ≤1.1A 3.0kgf.cm Package List: 1 x Gear Motor Note: 1. Please allow small size error due to manual measurement. Thanks for your understanding. 2. Only a gear motor, no other stuff included.
