DC12V Electric Linear Actuator Force 6000N Maximum Lift Stroke Waterproof Electric Motor Bracket Multiple Function Linear Actuator (200mm)

• Waterproof Linear Actuator : This Electric Linear Actuator Is Equipped With An All Metal Housing, Which Is Dustproof, Sturdy And Durable, As Well As Waterproof.
• Energy Saving Actuator : The Electric Motor Mount Is Quiet, Clean And Energy Efficient. Within The Entire Stroke, The Load Is Precisely Positioned At Variable And Repeatable Locations.
• Stable Actuator : This Electric Linear Actuator Provides Reliable Performance With Sensitive Action And Stable Running.

This liner actuator is a relatively fast-extending actuator available. Typical applications include driving electric gates, automatic windows and other home automation assemblies. The actuator may provide a pushing or pulling force of up to 6000N and a travel speed of up to 5mm/s when under no-load. Features: With reliable performance, sensitive action stable running. Good environment adaptability. Maximum push/pull is up to 6000N, and stroke speed is up to 5mm/s when under no-load. Commonly used in automotive, devices and engineering industry, agricultural machinery, wedding system, industrial electric lifting system, electric bed, surgical bed, traction bed, electric sofa, electric lifting lever, electric booth, electric sunroof, electric wheelchair, etc. Specification: Model: JS-TGZ-U3 Material: Metal Voltage: DC 12V Maximum push/pull: Approx. 6000n/6000n Optional stroke: 200mm, 100mm, 250mm, 350mm, 400mm, 450mm, 500mm No-load speed: Maximum 5mm/s Rated load rate: 5mm/s(600kg) Environment temperature: -26°C to +65°C Standard protection level: IP54 Built-in stroke switch: YesColor: Silver Weight: Approx. 2053g~3280g / 72.4oz~115.7oz Quantity: 1pc Package List: 1 x Linear Actuator sdfff Package List:1 x Linear Actuator
