Citronic CSL Range | Compact Mixing Consoles with Effects | 8 Inputs

• 24-bit 16 program DSP effects
• 48V phantom power for XLR inputs
• 3-band EQ per channel
• 7-band global graphic EQ
• IEC mains powered

CSL Series Compact Mixing Consoles with DSP Designed primarily for venues and stage applications, but suitable for much, much more. A compact yet comprehensive solution for mobile PA, bars and special events. Balanced mic/line inputs and 2 stereo inputs, each with 3-band EQ and aux send. A 16 program DSP section with tap tempo can provide vocal effects and a 7-band graphic EQ facilitates global tone control. PRODUCT FEATURES: ★ 24-bit 16 program DSP effects ★ 48V phantom power for XLR inputs ★ 3-band EQ per channel ★ 7-band global graphic EQ ★ IEC mains powered ★ Balanced main outputs SPECIFICATION: ★ Power supply 230Vac, 50Hz (IEC) ★ Phantom power +48V (XLR inputs) ★ Power consumption 25W ★ Fuse T1AL ★ Input level +24dBu ★ Output level : line +26dBu ★ Frequency response 20Hz-30kHz (0.5dB) ★ CMRR >74dB (mic 1kHz) ★ THD +N <0.01% (channel to main out) ★ Crosstalk >85dB (fader mute), >82dB (channel) ★ Noise rms : 22Hz-22kHz -122dBu (EIN), -82dBu (mix) ★ EQ: high 12kHz ±15dB shelving ★ EQ: mid 2.5kHz ±15dB band pass ★ EQ: low 80Hz ±15dB shelving ★ Input impedance : mic (balanced) 2k Ohms ★ Input impedance : line (balanced) 10k Ohms ★ Sensitivity : mic -60 to +14dBu ★ Sensitivity : line -40 to +14dBu ★ 2-track 2 x RCA in & out (-2dBu) ★ Effects 16 program DSP (24-bit sigma-delta, 40kHz) ★ Output impedance <75 Ohms ★ Headphone output 6.3mm jack, 30-600 Ohms VERSION SPEC: ★ Inputs : mic/line 4 x balanced XLRF/TRS jack ★ Dimensions 310 x 320 x 107mm ★ Weight 3.0kg
