CERRXIAN 1-Port PCI Express Parallel Card PCIe Expansion Card Adapter 25Pin Parallel Lpt to Parallel Db25 Printer Port Controller Card

• The DB25 Single Port Parallel PCIe Card can be installed in a PCIe slot, allowing you to connect SPP/ECP/EPP parallel peripheral to any computer system. Relying on a native single chip design, this adapter harnesses the true capability of PCI Express – ensuring maximum performance and reliability.
• Native single-chip, single lane PCI Express,complaint with PCI Express base specification revision 2.0
• SPP/ECP/EPP parallel port fully supports exiting Centronics interface
• One parallel port with data transfer rate up to 1.5Mbps
• Applications: Connects any parallel peripheral including printer, scanner, Zip drive, and memory card reader.

Bus Type：PCI Express Card Type： tandard/Low Profile Chipset ID：ASIX – AX99100 Industry Standards：IEEE 1284 PCI Express Base Specification Rev. 2.0 Interface： Parallel Port Style：Integrated on Card Ports：1 Maximum Data Transfer Rate：1.5Mbps Protocol：SPP/ECP/EPP Connector Type(s)：1 - PCI Express x1 Male External Ports：1 – DB-25 (25 pin, D-Sub) Female OS Compatibility：Windows 7, 8.x, 10 Windows Server 2008 R2, 2012, 2016 Linux 2.6.31 to 4.11.x LTS Versions only
