BG Nexus Grid Brushed Steel 20AX 2 Way 1 Pole Switch Module RBS12

• Simple secure 'locate & clip' fitting to frame
• 2 way switching allows for a second switch position in a circuit
• Captive backed out terminal screws for fast installation
• Module to be installed with Grid frame and plate
• Single pole
• Alternative legend rocker covers available
• Minimum mounting box depth 25mm
• Brushed Steel finish
• Terminal capacity: 4 x 1mm², 4 x 1.5mm², 2 x 2.5mm² & 1 x 4.0mm²
• Manufactured to BS EN 60669-2-1

Nexus Grid Brushed Steel 20AX 2 Way 1 Pole Switch Module The BG Electrical Nexus Grid RBS12 is a brushed stainless-steel single-pole 2-way switch module, rated at 20AX. A versatile switch module, the RBS12 is rated at 20AX, meaning it is suitable not only for everyday lighting purposes, but can also handle the inductive current from electric motors and fluorescent tubing. It’s easily fitted into a Nexus Grid frame and front plate – simply use the ‘locate & clip’ fitting which securely holds the module onto the frame. The brushed stainless-steel finish has a sleek, modern look and is lightly lacquered to reduce the impression of fingerprints. To aid installation, the RBS12 comes with captive terminal screws, helping to simplify wiring without the use of solder. A minimum back box depth of 25mm is required for this module.
