Bewinner 4G LTE Module, Wireless EM7455 4G LTE Module 300 Mbps Replacement 4G Module for Dell DW5811e Qualcomm 4G LTE WWAN NGFF Card Module

• Support : LTE Support (North America / EMEA) -B1 (2100 MHz), B2 (1900 MHz), B3 (1800 MHz), B4 (1700 MHz AWS), B7 (800 MHz-DD), B7 (800 MHz-B), B7 (2600 MHz), B8 (900 MHz), B8 (900 MHz), VITAMIN B12. B25 (1900 MHz), B26 (850 MHz), B29 (700 MHz-D block), B30 (2300 MHz), B41.
• HSPA + Support Band (Global) -B1 (2100 MHz), B2 (1900 MHz), B3 (1800 MHz), B4 (1700 MHz AWS), B5 (850 MHz), B8 (900 MHz).
• Notice : PCIe M.2 Form Factor, Qual comm Chipset, 52 pin, Best replacement for your cracked / damaged / faulted Module Card. Installation instruction is not included and professional installation is recommended.
• Application : 300 Mbps Wireless EM7455 4G LTE Module is used for Latitude 14 7000 Series E7470; For Latitude 12 7000 Series E7270; For Latitude 13 7000 Series E7370; For Latitude 15 5000 Series E5570; For Latitude 14 5000 Series E5470
• service: If you have any questions about the product or are not satisfied, please contact us at any time, we will offer the best solution for you.

Specifications: Category: 4G Module Chipset: Qual comm Form Factor: PCIe M.2 Pins: 52-pin Frequency bands: - LTE FDD: Band B1-B5, B7, B12, B13, B17, B20, B25,B26, B29, B30, B41 - UMTS/HSPA+: B1, B2, B3, B4, B5, B8 Technologies: UMTS, HSDPA, HSPA+, LTE Max Download Speed: 300 Mbps Max Upload Speed: 50 Mbps Temperature: -10 ℃ to 55 ℃ Certifications/Regulatory: Planned: FCC, IC, CE, NCC, GCF, PTCRB Carriers Approved: Planned: AT&T, Verizon, Sprint, Vodafone, Telefonica, Orange Connectors: Main, Aux/GNSS, GNSS Satellite Systems: GPS, Glonass, Beidou, Galileo Modes: Standalone, SUPL 2.0, XTRA 3.0 Control Options: APIs, AT Commands Voltage: 1.8V Active Antenna Control: 4 pin Dynamic Power Control: 1 pin Interfaces: USB 3.0, USB 2.0 High Speed SIM interface: 2 x 1.8V or 3V Audio: PCM/I2S Other interfaces: Main Radio Disable, GNSS Disable, Flash LED Output, Wake on WAN,Reset Dimensions: 42 x 30 x 2.3 mm Package Weight: About 7g Compatible for : For Latitude 14 7000 Series E7470 For Latitude 12 7000 Series E7270 For Latitude 13 7000 Series E7370 For Latitude 15 5000 Series E5570 For Latitude 14 5000 Series E5470 Package List: 1 * Wireless EM7455 4G LTE Module
