Bessey STC-HH50 STC-HH Toggle Clamp Open Arm, Grey/Red, 40 mm

• Adjustable clamping force up to 2,500 N depending on the setting screw in the joint
• Hole pattern of the base plate suitable for millimetres and inches
• Span wide: 40mm

BESSEY STC-HH50 Horizontal toggle clamp with open arm and horizontal base plate, BE102148 - One size of the BESSEY toggle clamp replaces multiple competitor sizes simultaneousl. In the clamped position, the lever is horizontal. Automatic and infinitely variable adjustment of the clamping height up to 35 mm while clamping force remains unchanged – without having to make manual changes to the position of the pressure screws. Clamping force is variable up to 2,500 N depending on the adjustment of the set screw in the cantilevered joint. Sturdy, tempered metal sheets for a long service life. Hole pattern on the base plate designed to facilitate fast and secure clamping set-up for metric and imperial. High-quality oil resistant two-component plastic handle
