Axing TVS 14-00 4x Distributor Amplifier for Small BK and Terrestrial Networks

• Amplifier for smaller antenna systems 47...862 MHz (VHF, DAB+, Freeview, DVB-T2) or CATV broadband networks/ cable television (DVB-C)
• Integrated 4-way distributor for connection of 4 end devices (e.g. TV, cable receiver, radio)
• Built-in power supply unit with LED operating indicator (power consumption 2.3 W), for direct plugging into the mains socket, EU Plug
• Gain 4 x 10 dB (max. 93 dBµV), input IEC socket, outputs IEC connector

This distribution amplifier is used in terrestrial antenna systems or cable networks. It effectively distributes and amplifies the signal in the frequency range from 47 to 862 MHz. This makes it easy to distribute VHF, DAB+ and DVB-T or DVB-C signals. The amplification power for each of the 4 outputs is 10 dB, adjustable via an attenuator. Suitable for cable television (CATV broadband cable network DVB-C, also for HDTV and UltraHD) and terrestrial antennas with FM, DAB+, Freeview and DVB-T2 HD reception. Power is supplied by the built-in power supply unit. The power consumption is 2.3 W. Connections: 1x IEC socket, 4x IEC plug. Dimensions: 80 x 140 x 60 mm.
