Axing BVS 2-01 house connection amplifier 25 dB for digital cable television (47-862 MHz)

• To amplify signals from cable connections or antenna systems (FM, VHF, UHF or DAB+, DVB-T) without a return channel
• The amplifier output can be precisely controlled via a damper, as can the equalization. Attenuation adjustable 20 dB, equalization adjustable 18 dB
• Housing with protection class IP20 and grounding terminal, connection input and output F socket
• Built-in power supply with a power consumption of 4 W, LED power indicator
• Box contents BK amplifier with built-in power supply
• For more information, see Product guides and documents.

This house connection amplifier can be used in all cable networks and effectively amplifies the television and radio signal, so that losses due to distributions and long cable runs are compensated. The maximum gain power of 25 dB can be reduced by means of attenuators and can therefore be optimally adapted to requirements. In order to achieve a frequency curve that is as linear as possible, the equalization can be adjusted. The equalization results in the sensitive higher frequencies receiving greater amplification. The result is consistently good signal quality, regardless of whether you are receiving with a television or a cable receiver. Suitable for cable television (BK broadband cable network DVB-C, also for HDTV and UltraHD) and terrestrial antennas with FM, DAB+, DVB-T and DVB-T2 reception. The power is supplied by the built-in power supply. The signal input and output are designed as F sockets. Attenuation: infinitely adjustable: 0... 20 dB; compensation: infinitely adjustable: 0... 18 dB; backflow loss: ≥ 14 dB (-1.5 dB/octave); noise ratio type: ≤ 7 dB
