Alda PQ Antenna with magnetic stand for 2G (GSM), 3G (UMTS) with SMA/M plug and 2.5m (2.73 yd) cable 5 dBi gain

• Suitable for networks/frequencies: GSM (900 MHz)
• Suitable for networks/frequencies: 3G (UMTS 2.1 GHz)
• Gain: 5 dBi, Connector type: SMA/M, Cable type: RG174, Cable length: 2.5m
• Due to its size and weight, the antenna is very suitable for mobile and stationary use, as the antenna can be attached to all metallic surfaces thanks to the magnetic base.
• Areas of application are: trucks, cars, vehicles, means of transport, containers, ships, camping, indoor, living room, embedded systems, PC housing, control cabinets, telematics, navigation, commercial premises, M2M, IOT, industry 4.0.

Alda PQ Antenna with magnetic base for 2G (GSM), 3G (UMTS) with SMA/M plug and 2.5 m cable 5 dBi gain Specification: Frequencies: GSM (900 MHz). 3G (UMTS 2.1 GHz). Connector type: SMA/M Cable length: 250 cm Cable type: RG174 Construction and dimensions: Mounting type: Stub antenna for attaching to all metallic surfaces by means of magnetic surface. Areas of application: Truck, car, transport, containers, ships, camping, indoor, living space, embedded systems, PC housing, control cabinets, telematics, navigation, commercial premises, M2M, IOT, industry 4.0. Maximum dimensions: 31.05 mm x 308 mm (diameter x length). Impedance: 50 ohms. Polarisation: Vertical. Reinforcement: 5 dBi maximum. Standing Wave Ratio (VSWR): Under 2:1 Max. Input power: 25w Environmental conditions: Temperature range: from -40 °C to +85 °C. Package includes: Antenna with magnetic base and cable. Made in the EU.
