Alda PQ Antenna for roof mounting for 2G (GSM), 3G (UMTS), GPS, WIFI/BLUETOOTH with FME/M and FME/F plug 2.2 dBi gain

• Geeignet fr die Netze / Frequenzen: GSM (900 MHz), 3G (UMTS 2,1 GHz)
• Geeignet fr die Netze / Frequenzen: GPS (1575,42 MHz), WIFI / BLUETOOTH (2,4 GHz)
• Reinforcement / gain: 2.2 dBi, connector type: FME/M and FME/F
• The weatherproof antenna is very suitable for permanent use on vehicles. Die Verschraubung erfolgt von unten ber ein Stellmutter.
• Areas of application: antenna for stationary use, e.g. cars, trucks, s, housing, automatic machines and other thin surfaces

Alda PQ Antenna for roof mounting for 2G (GSM), 3G (UMTS), GPS, WiFi/Bluetooth with FME/M and FME/F plug 2.2 dBi gain. Specification: Frequencies: GSM (900 MHz). 3G (UMTS 2.1 GHz). GPS (1575.42 MHz). WiFi/Bluetooth (2.4 GHz). Connector type: FME/M and FME/F. Construction and dimensions: Mounting type: Shark fin antenna for roof mounting for stationary operation on vehicles and housings. Areas of application: Screw antenna for stationary use, e.g. cars, trucks, ships, housings, vending machines and other thin surfaces. Maximum dimensions: 64 mm x 98 mm x 59.5 mm (height x length x width). Impedance: 50 ohms. Polarisation: Vertical. Reinforcement: 2.2 dBi maximum. Standing Wave Ratio (VSWR): Under 2:1 Max. Input power: 50W Environmental conditions: Temperature range: from -40 °C to +85 °C. Package includes: Antenna with screw connection for roof mounting. Made in the EU.
