aeco BNC Plug ABC-1451, 2pcs/1set, 50ohm, Gold Plating, Vacuum bag
About this item
- In a specified size range for the cables, it will allow cables to maintain a regular percentage of the section conductor and insulation diameter ratio after complete assembly and also achieve the best transmission effect.
- It’s allow to connect conductor by solder or crimp
- The conduct material is made by high pure copper (beryllium copper) and plated without nickel base.
Product description
Material: Contact Pin: beryllium Copper (#C17300 / copper contain 97% at least) Body: Brass Zinc alloy (#C3604) Spring: Steel Washer: Steel Shell: Brass Zinc alloy(#C3604) Screw: Stainless Steel(#SUS304)Finish: Contact Pin: 10u" gold plating (no nickel base) Body: 10u" gold plating (no nickel base) Spring: Nickel plating Washer: Nickel plating Shell: Satin nickel plating + topcoat Screw: NatureElectrical Characteristics:Impedance: 50 ohms Frequency Range: 1GHz VSWR: up to 1.2 Contact resistance <0.1 mOhmDimension: Cable Hole: 10.5mm Sleeve Hole: 6.5/8.5mm Biggest OD: 14.5mm Total Length: 42.0mmThe corresponding of the cable size: Center conductor <01.5mm Insulation OD >03.0mm Woven shield OD>07.5mm Outer plastic sheath OD <10.5mmmore info:https://www.aeco.tw/en-abc-14.html
Product details
