AC Multimeter 6in1 Combo Meter Voltage 110V 220V Current 100A Power Factor KWH Frequency Multifuction Tester

• The meter can only measure the active power(real power). It doesn't show Apparent power. If you measure power from a DC-AC inverter please make sure it's PURE SINE WAVE. Otherwise the meter can be burnt or melted
• The blue backlight can be turned on/off manually. The CT can be either on Live line or Neutral Line.
• Voltage test range: One-Phase 110~250V AC Power, 50/60HZ; Current test range: 0~100A;
• Store energy data when power off(can be reset). w/ Open-close structure Current Transformer. Inner diameter of the CT: 15mm/0.6''
• Large-screen LCD (display voltage, current, active power, energy at the same time).

Key Feature: This combo meter is designed to monitor AC power, it combines many functions in one. •Voltage 110~250Vac •Current 0.01-100A •Energy 5-digits, 0.01~99999KWH •Compatible frequency 50/60HZ •Come with small current transformer (diameter 12.5mm) •Backlight control, short press to turn on/off backlight •Clear energy reading, press and hold down the key to clear the reading of kWh. Technical Specification: Power Supply 110~250Vac (self-powered) Voltage Range 110V~250V Current Range 0.01~100A Resolution 1V, 0.01A, 0.01W, 0.01kWh Display Type LCD Dimensions 84mm*46mm*28mm Items include: 1*AC Combo Meter 1*CT 1* Wiring diagram
