ABB DS201A-B16 DS201A-B16/0.03 FI/LS Switch 6kA, 1P+N, Type A, B 16, 30mA, Grey, 2 TE

• Number of poles: 2
• Number of protected poles: 1
• Rated current: 16 A
• Fault current type: Type A
• Rated fault current: 30 mA

FI/LS switches (RCBOs) offer personal and property protection as well as protection against electrically ignited fires according to DIN VDE 0100-410 and DIN VDE 0100-530. They ensure protection of single-phase circuits against overload and short circuit currents, protection against sinusoidal AC currents and pulsating currents with smooth DC current content of up to 6 mA against earth. As well as fault protection (protection in the event of indirect contact), additional protection (30 mA) and fire protection (300 mA). They meet the product standards IEC/EN 61009-1 (VDE 0664-20), IEC/EN 61009-2-1 (VDE 0664-21). Areas of use include household, commercial and industrial applications. The extensive range of accessories offers you everything you need for installation tasks. Numerous approvals make the DS201 fit for worldwide use. Rated switching capacity according to IEC/EN 61009 Icn = 6 kA. RCBO DS201 A type A is 1-pin protected (LS), 2-pin switching.
