4 Channel 0/1-10V LED Dimming Controller 4CH 5A/CH Smooth Dimming without any flickering 12-36VDC

• 4 channel 0/1-10V LED dimming controller with push-dimming function.
• 4 channel 0/1-10V input, 4 channel PWM constant voltage output.
• 0~100% dimming range via logarithmic characteristic can be very comfortable for human eyes.
• Smooth dimming without any flickering.
• Compatible with active or passive 0-10V, 1-10V access dimmer, can solve the fluorescent lamp dimming system compatible with LED lighting.

Feature/b> 1.4 channel 0/1-10V LED dimming controller with push-dimming function. 2.4 channel 0/1-10V input, 4 channel PWM constant voltage output. 3.0~100% dimming range via logarithmic characteristic can be very comfortable for human eyes. 4.Smooth dimming without any flickering. 5.Compatible with active or passive 0-10V, 1-10V access dimmer, can solve the fluorescent lamp dimming system compatible with LED lighting. 6.0/1-10V CV LED dimming controller can connect unlimited number of CV or CC power repeaters in series or in parallel to expand output power, achieve synchronous control effect. Technical Parameter:/b> Working Voltage: 12-36VDC Output Current: 4CH, 5A/CH Output Power: 4x(60-180)W Output Type: Constant Voltage
