12V 24V 30A 50ASolar Controller, Solar Panel Battery Regulator Dual USB LCD Display Renewable Energy Controllers (50A)renogy mppt

• 【LCD Displaying and Double Button of Man-machine Interface】Humanized LCD displaying and double button of man-machine interfac, solar panel battery regulator can be conveniently switched modes and parameter configuration
• 【Automatic Identification System Voltage】Solar controller has an automatic identification system voltage, 12/24V auto recognition
• 【Multiple Electric MPPT solar controller has over voltage protection, short circuit protection, over load protection, overcharge protection, over-discharge protection,more safety for using, suitable for home, industrial, commercial etc
• 【Long Battery Lifetime】Accurate temperature compensation, correcting the charging and discharging voltage automatically, 70A solar controller improves the battery lifetime
• 【Negative MOSFET】Solar panels, battery, solar controller positive poles are all connected together, adopting negative MOSFET in series control circuit

Specifications: Current: 30A, 50A, 70A (optional) Rated Voltage: 12/24V USB Output: 2.4A *2 Over Current(V): 13.7V/*2 24V Over Discharge Current(V): 10.5-11V/*2 24V Temperature Compensation: -3mv/℃/cell Empty Load Wastage: <45mA Loop Voltage Drop: <200mv Display: LCD Display Charging Type: MPPT Waterproof Grade: IP32 Material: Plastic Color: Black + Orange Size: 17.5 * 14 * 4cm/6.9 * 5.5 * 1.6in(30A), 21 * 19.2 * 5.5cm/8.3 * 7.6 * 2.2in(50A), 22.8 * 20 * 5.5cm/9 * 7.9 * 2.2in(70A) Package Weight: 480g-1284g Package List: 1 * Solar Controller 1 * User Manual Notes: 1. The function of controller is to protect voltage overshoot and overplay. 2. When the battery voltage is too low, the controller stops the output; after the solar panel is charged, the cell recovers to 12.6V. 3. 12.6V is the recovery discharge voltage. 4. The normal voltage of the controller is 10.7V to 13.7V. These two voltage fluctuations can be set manually. If you have trouble in use, try adjusting the float voltage to 13.7V: First, you need to press the MCU control button for about 3-4 seconds, and then there will be a management interface on the screen. Second, you must press the add button on the screen until the voltage reaches 13.7V. Finally, you need to press the MCU control button again, which will save the controller record data when the display does not flicker.
