Nutbro 0/1-10V LED Dimmer 1CH 12A Constant Voltage Single Channel LED Dimmable Driver DC12-36V

• High Power 1CH 12A 0/1-10V LED dimming controller.
• 1 channel 0/1-10V input, 1 channel PWM constant voltage output.
• 0~100% dimming range via logarithmic characteristic can be very comfortable for human eyes.
• Smooth dimming without any flickering.
• Compatible with active or passive 0-10V, 1-10V access dimmer, can solve the fluorescent lamp dimming system compatible with LED lighting.

Feature/b> 1.High Power 1CH 12A 0/1-10V LED dimming controller. 2.1 channel 0/1-10V input, 1 channel PWM constant voltage output. 3.0~100% dimming range via logarithmic characteristic can be very comfortable for human eyes. 4.Smooth dimming without any flickering. 5.Compatible with active or passive 0-10V, 1-10V access dimmer, can solve the fluorescent lamp dimming system compatible with LED lighting. 6.0/1-10V CV LED dimming controller can connect unlimited number of CV power repeaters in series or in parallel to expand output power, achieve synchronous control effect. Description:/b> 0/1-10V to PWM dimming driver is compatible with the active/passive 0-10V,1-10V, 10V PWM signal dimming,which has solved the compatible problemof the fluorescent dimming system and the LED illumination. LED lamps can be controlled by many traditional intelligent dimming systems. Technical Parameter:/b> Working Voltage: 12-36VDC Input signal: 0/1-10V Output Type: PWM constant voltage Output Current: 1CH, 12A Output Power: 144-432W Dimming range: 1~100% Working temperature: -30¡æ~55
