0/10V 1CH 8A Dimmable Switches Driver 1 Channel 0-10V Constant Voltage LED Dimmer PWM 5-36V

• Working Voltage: 5-36VDC
• Input signal: 0/1-10V
• Output Type: PWM constant voltage
• Output Current: 1CH, 8A
• Output Power: 40-288W

Features: 1.1 channel 0/1-10V input with 1 channel PWM output. 2.Apply to any single color LED low voltage lamps,automatically adapt to the input voltage range. 3. 0~100% dimming range. 4.MCU internal PWM hardware to achieve flickerless dimming. 5.Ultra smooth dimming with 15-bit resolution PWM,4096 levels of Grey Scale. Description: 0/1-10V to PWM dimming driver is compatible with the active/passive 0-10V,1-10V, 10V PWM signal dimming,which has solved the compatible problemof the fluorescent dimming system and the LED illumination. LED lamps can be controlled by many traditional intelligent dimming systems. Technical Parameter: Working Voltage: 5-36VDC Input signal: 0/1-10V Output Type: PWM constant voltage Output Current: 1CH, 8A Output Power: 40-288W Dimming range: 1~100% Working temperature: -30¡æ~55 Product Size: L97¡ÁW33¡ÁH18mm Net weight:42g
